●Suitable for extremely harsh industrial environments with corrosive coolants and lubricants, it has excellent oil resistance and abrasion resistance.
●Polyurethane Drag Chain Power Cable has good resistance to microorganisms, hydrolysis, chemical corrosion, UV, and low temperatures.
●Can be used indoors and outdoors in dry or humid conditions, especially suitable for industrial environments.
●Under normal operating conditions, the service life is generally over 5,000,000 cycles, suitable for use in medium to high-speed drag chains.
●Mainly used for power transmission in harsh industrial automation, electromechanical equipment, machine tools, and servo systems.
| YP507 HIGH FLEXIBLE PUR DRAG CHAIN POWER CABLE (STANDARD COLOR CORE) ( 5 million times reliability tests for drag chain) | ||||
| No. | Product Code | Cores Number and cross-sectional area | Approximate outer diameter （mm) | Outer sheath color |
| (NO.Xm㎡) | ||||
| 1 | YP507.02.0050 | 2×0.5 | 5.8 | Black/Orange |
| 2 | YP507.02.0051 | 3G0.5 | 6.2 | Black |
| 3 | YP507.02.0052 | 4G0.5 | 6.8 | Black/Orange |
| 4 | YP507.02.0053 | 2×0.75 | 6.2 | Black |
| 5 | YP507.03.0075 | 3G0.75 | 6.6 | Black |
| 6 | YP507.03.0076 | 4G0.75 | 7.2 | Black/Orange |
| 7 | YP507.03.0077 | 4G0.75+2×0.3 | 8.0 | Black/Orange |
| 8 | YP507.03.0078 | 2×1.0 | 6.6 | Black |
| 9 | YP507.03.0079 | 3G1.0 | 7.0 | Black |
| 10 | YP507.03.0080 | 4G1.0 | 7.8 | Black/Orange |
| 11 | YP507.03.0081 | 2×1.5 | 7.8 | Black |
| 12 | YP507.03.0082 | 3G1.5 | 8.2 | Black |
| 13 | YP507.03.0083 | 4G1.5 | 8.8 | Black/Orange |
| 14 | YP507.03.0084 | 3×1.5+1G1.0 | 8.8 | Black |
| 15 | YP507.03.0085 | 4G1.5+2×0.5 | 10.5 | Black/Orange |
| 16 | YP507.03.0086 | 2×2.5 | 9.2 | Black |
| 17 | YP507.03.0087 | 3G2.5 | 9.8 | Black |
| 18 | YP507.03.0088 | 4G2.5 | 11.0 | Black/Orange |
| 19 | YP507.03.0089 | 3×2.5+1G1.5 | 11.0 | Black/Orange |
| 20 | YP507.02.0400 | 2×4.0 | 11.2 | Black |
| 21 | YP507.03.0400 | 3G4.0 | 11.8 | Black |
| 22 | YP507.04.0400 | 4G4.0 | 13.0 | Black/Orange |
| 23 | YP507.04.0600 | 4G6.0 | 14.5 | Black/Orange |
| 24 | YP507.04.1000 | 4G10.0 | 19.5 | Black/Orange |
| 25 | YP507.04.1600 | 4G16.0 | 23.0 | Black/Orange |
Polyurethane Drag Chain Power Cable Technical data
●Specialized PUR sheath, highly flexible
●Temperature range: Mobile installation: -20°C to +80°C Fixed installation: -40°C to +90°C
●Maximum overhead/sliding speed: 5 m/s, 3 m/s
●Maximum acceleration: 50 m/s
●Rated voltage Uo/U: 300/500V
●Test voltage: 4000V
●Insulation resistance: Minimum 20 MOhms per kilometer
●Minimum bending radius: Mobile installation: 6.8x cable diameter Fixed installation: 6x cable diameter
●Compliant with EU RoHS and Reach regulations.
Polyurethane Drag Chain Power Cable Structure
●Bare copper conductor, fine copper wire Compliant with DIN VDE 0295 Class 6 and IEC 60228 Class 6
●Special PVC insulation
●Color-coded core identification Optimal pitch twisted layer for the cores
●Includes a yellow-green grounding wire (for 3 cores and above)
●Low friction, wear-resistant, low-temperature resistant, and oil-resistant PUR composite material.
●Grey,orange, black, or color can be customized according to customer requirements.
| High Flexibility 5 Million Times Drag Chain Cable Test Standards | ||
| Drag Chain Bending Test Test Method: Take a 2-meter finished cable, with a bending radius of 6 times the outer diameter of the cable, a moving stroke of 900 mm, and reciprocating movement at a speed of 90 times/minute. |
Two-Wheel Winding Test Test Method: Take a 5-meter finished cable, according to the specified pulley diameter and weight of the weights. The pulley moves at a speed of 0.33 m/sec, and the moving distance is more than 1.0 meter under reciprocating conditions |
90-Degree Bend Test Test Method: Take a 2-meter finished cable, with a bending radius of 2.5 times the outer diameter of the cable, according to the standard specified weight of the weights, bending at a speed of 40 times/minute |
| Judgment Criteria: 1. The number of reciprocations exceeds 5,000,000 times without open circuit or short circuit. 2. The sheath is not broken | Judgment Criteria: 1. The number of reciprocations exceeds 200,000 times without open circuit or short circuit. 2. The sheath is not broken | Judgment Criteria: 1. The number of reciprocations exceeds 100,000 times without open circuit or short circuit. 2. The sheath is not broken |
