Industrial Ethernet PUR Cable For Cable Tracks Features
- Moving speed: 3m/s to 10m/s.
- Bending life: 20 times/minute to 50 times/minute, >3 million times, >5 million times, >8 million times.
- Excellent flexibility, oil resistance, shallow water resistance, UV resistance, and weather resistance.
- Cold resistance, wear resistance, able to withstand heavy mechanical external forces.
- our drag chain cables have faster acceleration and stronger bending resistance compared to ordinary flexible cables.
- Stable signal transmission characteristics (anti-interference, anti-crosstalk) of polyurethane (shielded) drag chain cables.
- Cold resistance, water resistance, resistance to microbial, oil, and coolant.
- Radiation resistance, ozone resistance, weather resistance, resistance to acid, alkali, salt spray corrosion, and solvent resistance.
- High abrasion resistance, scratch resistance, Jiarou polyurethane (shielded) drag chain cables can withstand tension and heavy mechanical loads.
- Bending resistance, torsion resistance, good electromagnetic properties, and stable signal transmission characteristics.
Industrial Ethernet PUR Cable Technical Parameter
●Special PUR sheath.
●Compliant with bus cable specifications.
●Temperature range: Mobile installation: -5°C to +70°C. Fixed installation: -15°C to +70°C.
●Nominal voltage: 30V.
●Test voltage: 500V.
●Minimum insulation resistance: 20 MOhmxkm.
●Minimum bending radius: Mobile installation: 14x cable diameter. Fixed installation: 7x cable diameter.
●Compliance with EU RoHS and Reach regulations.
● Single or twisted bare copper conductors, compliant with DIN VDE 0295 and IEC 60228 standards.
● Insulation compliant with bus standards.
● Core wire identification compliant with bus standards.
● Twisting method compliant with bus standards.
● Improved tinned copper braided shield.
● Minimum overall shielding rate of 80%.
● Special PUR outer sheath. Purple (RAL 4001) matte grey (RAL 7001) matte
| Industrial Ethernet PUR Cable Parameter | ||||
| No. | Product Code | Cores Number and cross-sectional area | Approximate outer diameter （mm) | Outer sheath color |
| (NO.Xm㎡) | ||||
| 1 | BUS-HP506.08.0014 | 4x2x0.14 | 6.5 | Black Green |
| 2 | BUS-HP1006.08.0020 | 4x2x0.2 | 7 | Black Green |
| Ethernet/CAT6A Parameter | ||||
| No. | Product Code | Cores Number and cross-sectional area | Approximate outer diameter （mm) | Outer sheath color |
| (NO.Xm㎡) | ||||
| 1 | BUS-HP506.08.0014 | 4x2x0.14 | 6.5 | Black Green |
The MOQ for the above cable is one roll (100 M). If the cable with PUR sheath, the MOQ is 400 meters. For more specifications or special custom products, please contact our product consultant.
PUR (available) has oil resistance, high abrasion resistance, UV resistance, acid and alkali resistance, chemical corrosion resistance, and resistance to various lubricants.
PUR (available) is resistant to low temperature, especially strong, impact-resistant, and can be selected for hydrolysis resistance.
Special models with customized conductor cross-sectional area, material, shielding, different colored cores, and other specifications of the sheath can be customized according to requirements.
