Low -speed motion twisted data transmission twisted pair encoder servo Cable have a long life and cost -effective. The PVC
material makes it wear -resistant and stable, suitable for indoor. Flexible data transmission PVC cables can transmit analog
digital signals in devices with control processors, or use the connection cable between the instrument and the control device
to be applied to the uninterrupted transmission transmission. The shielding layer uses a double -layer shielding of tin -plated
copper+aluminum foil to reduce oxidation; the coverage rate of low -speed sports cable reaches 65%, reducing interference
during use. The delivery is fast and cost -effective. The color of the outer cover is: black, customers can choose other colors
according to their needs, non -inventory products need to be customized.
Technical Parameter Twisted Pair Encoder Servo Cable
|
Standard
|
Comply with UL20276 standard, thin wire diameter design
|
|||
|
Conductor
|
adopts high-quality tinned copper stranded copper wire
|
|||
|
Insulation material
|
Modified PVC
|
|||
|
Core structure
|
Small pitch single stranding
|
|||
|
Core recognition
|
Below 0.5m㎡ is marked with colored core wires; 0.5m㎡ above, a yellow-green ground wire + black core wire with white numbers
|
|||
|
Outer sheath
|
Modified PVC mate
|
|||
|
Color
|
black (other colors can be customized)
|
|||
|
Bending radius
|
Move in is more than 7.5 x d, Fixed laying is more than 6 x d,
|
|||
|
Nominal voltage
|
Uo/U 300/300 V
|
|||
|
Test voltage
|
1500 V
|
|||
|
Application:
|
It is especially suitable for fixed installation of mechanical equipment and machine tools or occasional mobile applications. The flexible cable uses specially modified insulation and sheath materials, has abrasion resistance and medium resistance, and has more than one million periodic bends, and always maintains stability.
|
|||
Twisted Pair Encoder Servo Cable Structure
1. Tinned copper (less than 0.5m㎡) or bare copper (0.5m㎡ and above) conductor thin copper wire, in line with DIN VDE0295 category 6 and IEC 60228 category 6
2. Special PVC insulation
3. Color core wire identification (less than 0.5m㎡)
4. Black core wire with continuous white digital code (0.5m㎡ and above)
5. The wire core is stranded in layers with the best pitch
6. Improved tinned copper wire braided shield
7. The minimum comprehensive shielding rate is 80%
8. Special PVC outer sheath
9. Black (RAL 9005) matte
|
No.
|
Product Code
|
Cores Number and cross-sectional area
(NO.Xm㎡)
|
Approximate outer diameter （mm)
|
Outer sheath color
|
20℃ Conductor DC resistance
Ω/km
|
|
1
|
YY06.04.0014
|
2x2x0.14
|
5.5
|
Black
|
150
|
|
2
|
YY06.06.0014
|
3x2x0.14
|
5.6
|
Black
|
150
|
|
3
|
YY06.08.0014
|
4x2x0.14
|
6.2
|
Black
|
150
|
|
4
|
YY06.10.0014
|
5x2x0.14
|
6.8
|
Black
|
150
|
|
5
|
YY06.12.0014
|
6x2x0.14
|
7.0
|
Black
|
150
|
|
6
|
YY06.14.0014
|
7x2x0.14
|
7.5
|
Black
|
150
|
|
7
|
YY06.16.0014
|
8x2x0.14
|
7.8
|
Black
|
150
|
|
8
|
YY06.20.0014
|
10x2x0.14
|
8.5
|
Black
|
150
|
|
9
|
YY06.26.0014
|
13x2x0.14
|
9.3
|
Black
|
150
|
|
10
|
YY06.04.0020
|
2x2x0.2
|
5.6
|
Black
|
95
|
|
11
|
YY06.06.0020
|
3x2x0.2
|
6.0
|
Black
|
95
|
|
12
|
YY06.08.0020
|
4x2x0.2
|
6.8
|
Black
|
95
|
|
13
|
YY06.10.0020
|
5x2x0.2
|
7.2
|
Black
|
95
|
|
14
|
YY06.12.0020
|
6x2x0.2
|
7.6
|
Black
|
95
|
|
15
|
YY06.14.0020
|
7x2x0.2
|
8.0
|
Black
|
95
|
|
16
|
YY06.16.0020
|
8x2x0.2
|
8.5
|
Black
|
95
|
|
17
|
YY06.20.0020
|
10x2x0.2
|
9.2
|
Black
|
95
|
|
18
|
YY06.04.0030
|
2x2x0.3
|
6.2
|
Black
|
71.2
|
|
19
|
YY06.06.0030
|
3x2x0.3
|
6.6
|
Black
|
71.2
|
|
20
|
YY06.08.0030
|
4x2x0.3
|
7.3
|
Black
|
71.2
|
|
21
|
YY06.10.0030
|
5x2x0.3
|
7.8
|
Black
|
71.2
|
|
MOQ 1 meter, If you need to order PUR outer sheath, MOQ 400 meters
|
|||||
