The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012
* Main of cables features
1,Uo/U is 450/750V,300/500,
2,Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105℃, the allowable
3, temperature of other models should not exceed 70℃.* Application:
Applicable to the cables and wires of rated volatage 450/750V and less than 450/750V AC for power
plant, house hold electrical appliance,insutrment and telecommunication equipment.
* Main of cables features
1,Uo/U is 450/750V,300/500,
2,Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105℃, the allowable
3, temperature of other models should not exceed 70℃.* Application:
Applicable to the cables and wires of rated volatage 450/750V and less than 450/750V AC for power
plant, house hold electrical appliance,insutrment and telecommunication equipment.
Technical Parameter
|
Standard
|
Comply with UL20276 standard, thin wire diameter design
|
|||
|
Conductor
|
adopts high-quality tinned copper stranded copper wire
|
|||
|
Insulation material
|
Modified PVC
|
|||
|
Core structure
|
Small pitch single stranding
|
|||
|
Core recognition
|
Below 0.5m㎡ is marked with colored core wires; 0.5m㎡ above, a yellow-green ground wire + black core wire with white numbers
|
|||
|
Outer sheath
|
Modified PVC mate
|
|||
|
Color
|
black (other colors can be customized)
|
|||
|
Bending radius
|
Move in drag chain is more than 7.5 x d, non-tow chain is moved more than 6 x d,
fixed laying is more than 5 x d
|
|||
|
Movement speed:
|
fixed or low-speed movement, less than 0.3 m/s
|
|||
|
Travel distance
|
Fixedly laid, less than 30 meters, and the signal is attenuated if it is too long.
|
|||
|
Nominal voltage
|
Uo/U 300/300 V
|
|||
|
Test voltage
|
1500 V
|
|||
|
Application:
|
Suitable for various non-standard automated production equipment such as CNC machine tools, industrial robots, servo drives,
woodworking machinery, mask machines, manipulators, dispensing machines, laser equipment, stamping lines, logistics automation, ceramic production equipment, etc., which can withstand long-term acceleration, Deceleration, tensile and compressive stress, and high-speed periodic bending, and always maintain high stability. |
|||
Cable Structure
