Ul20276 80 Degree Flex Encoder Data and Communication Cables
This flexible cable is particularly suitable for the fixed installation or occasional mobile applications of mechanical equipment and machine tools. The cable utilizes specially modified insulation and sheath materials, providing abrasion resistance, media resistance, and the ability to withstand over a million cycles of bending while maintaining stability.
| UL2464 80 DEGREE FLEX POWER CABLE(AMERICAN CORE WIRE) (2 million times reliability tests for drag chain) | ||||
| No. | Product Code | Cores Number and cross-sectional area | Approximate outer diameter （mm) | Outer sheath color |
| (NO.Xm㎡) | ||||
| 1 | MC-YY06.04.0014 | 2x2x0.14 | 5.9 | Black |
| 2 | MC-YY06.06.0014 | 3x2x0.14 | 5.9 | Black |
Encoder Data and Communication Cables Technical Parameter
● Special PVC sheath with good flexibility.
● Temperature range: Mobile installation: -5°C to +70°C. Fixed installation: -15°C to +80°C.
● Nominal voltage Uo/U 300/300V.
● Test voltage: 1500V.
● Insulation resistance: Minimum 20 MOhmxkm.
● Minimum bending radius: Mobile installation: 7.5x cable diameter. Fixed installation: 6x cable diameter.
● Compliance with EU RoHS and Reach regulations.
Encoder Data and Communication Cables Structure
●Tinned copper conductor, fine copper wire in accordance with DIN VDE 0295 Class 6 and IEC 60228 Class 6.
●Special PVC insulation.
●Color-coded core wire identification.
●Optimum lay-up with twisted layers of conductors.
●Enhanced tinned copper wire braided shield.
●Minimum overall shield coverage 80%.
●Special PVC outer sheath.
●Black color (RAL 9005) with a matte finish.
