YP506 3X2X0.2mm²(24AWG) PUR drag chain conveyors polyurethane cable twisted pair
drag chain conveyors polyurethane cable is a widely used cable type in many industrial and commercial applications.
This cable is popular mainly due to its special materials and design, which provide excellent performance, especially in flexibility, wear resistance, oil resistance, and high and low temperature resistance
drag chain conveyors polyurethane cable twisted pair Parameter
YP506 HIGH FLEXIBLE DRAG CHAIN DATA PUR CABLE ( 5 million times reliability tests for drag chain)) | ||||
아니요. | 제품 코드 | 코어 수 및 단면적 | 대략적인 외경(mm) | 외피 색상 |
(NO.Xm㎡) | ||||
1 | YP506.04.0020 | 2x2x0.2 | 5.8 | Black/ Green |
2 | YP506.04.0021 | 2x2x0.3 | 6.8 | Black/ Green |
삼 | YP506.04.0022 | 2x2x0.4 | 7.8 | Black/ Green |
4 | YP506.04.0023 | 2x2x0.5 | 8.8 | Black/ Green |
drag chain conveyors polyurethane cable twisted pair Technical data
Special PUR sheath with high flexibility
●Temperature range: Mobile installation -20°C to +80°C
Fixed installation -40°C to +90°C
●공칭 전압 Uo/U 300/300V
●시험전압 1500V
●절연 저항: 최소 20MOhm x km
●최소 곡률 반경: 모바일 설치 케이블 직경의 7.5배
고정 설치 6x 케이블 직경
●Complies with EU RoHS and Reach regulations requirements
drag chain conveyors polyurethane cable twisted pair Structure:
●Tinned copper (below 0.5mm²) or bare copper (0.5mm² and above) conductors Fine copper wire,
compliant with DIN VDE 0295 class 6 and IEC 60228 class 6
●특수 PVC 단열재
●Color-coded cores (below 0.5mm²)
●Black cores with continuous white numerical coding (0.5mm² and above)
●Optimum lay length of stranded cores
●개선된 주석 도금 구리선 편조 차폐
●Minimum overall shielding coverage of 80%
●특수 PVC 외피
●Black color (RAL 9005) with matte finish
![높은 유연성 제어 드래그 체인 케이블 테스트 기계](http://sc04.alicdn.com/kf/H1262107d55ec483eaf5930e4896b8879v/257605182/H1262107d55ec483eaf5930e4896b8879v.png)
높은 유연성 5백만 회 드래그 체인 케이블 테스트 표준 | ||
드래그 체인 굽힘 테스트 테스트 방법: 케이블 외경의 6배 굽힘 반경, 900mm의 이동 스트로크, 90회/분의 속도로 왕복 운동하는 2m 완성 케이블을 사용합니다. |
2륜 와인딩 테스트 테스트 방법: 지정된 풀리 직경과 무게추의 무게에 따라 완성된 5미터 케이블을 가져옵니다. 풀리는 0.33m/sec의 속도로 이동하며, 왕복운동 조건에서 이동거리는 1.0m 이상입니다. |
90도 굽힘 테스트 테스트 방법: 표준 지정 중량의 분동에 따라 케이블 외경의 2.5배 굽힘 반경을 갖는 2m 완성 케이블을 40회/분의 속도로 구부립니다. |
판단 기준: 1. 개방 회로 또는 단락 없이 왕복 횟수가 5,000,000회를 초과합니다. 2. 칼집이 부러지지 않음 | 판단 기준: 1. 개방 회로 또는 단락 없이 왕복 횟수가 200,000회를 초과합니다. 2. 칼집이 부러지지 않음 | 판단 기준: 1. 개방 회로 또는 단락 없이 왕복 횟수가 100,000회를 초과합니다. 2. 칼집이 부러지지 않음 |
