차폐된 유연한 전원 PVC 케이블

차폐된 유연한 전원 PVC 케이블

고정 및 이동 애플리케이션을 위한 YY08 7C0.75 가려진 유연한 전원 PVC 케이블

This Screened Flexible Power PVC Cables is an ideal choice specifically designed for fixed installations or occasional mobile applications in mechanical equipment and machine tools. It uses specially modified insulation and sheathing materials to provide excellent wear resistance and resistance to various media, while being able to withstand millions of cycles of bending with consistent stability. In the working environment of mechanical equipment and machine tools, this flexible cable shows outstanding reliability, ensuring the quality and stability of signal transmission. Whether it is sudden movements or frequent motion, it can adapt and provide continuous reliable power, signal, and data transmission.

견적에 추가

카테고리: 유연한 케이블, 유연한 전원 케이블 태그: PVC, UL

설명

고정 및 이동 애플리케이션을 위한 YY08 7C0.75 가려진 유연한 전원 PVC 케이블

Chengjia 케이블의 주요 제품 — This Screened Flexible Power PVC Cables is an ideal choice specifically designed for fixed installations or occasional mobile applications in mechanical equipment and machine tools. It uses specially modified insulation and sheathing materials to provide excellent wear resistance and resistance to various media, while being able to withstand millions of cycles of bending with consistent stability. In the working environment of mechanical equipment and machine tools, this flexible cable shows outstanding reliability, ensuring the quality and stability of signal transmission. Whether it is sudden movements or frequent motion, it can adapt and provide continuous reliable power, signal, and data transmission.

모델	심수 및 단면적(MM²)	와이어 색상	MOQ
YY08 Flexible Power Shield Cable	0.5	Yellow/Green Blue Brown Red	A minimum order quantity of one coil is required for cables with 2, 3, or 4 cores. For other combinations of cores and colors, the minimum order quantity is 400 meters. If a color is not available, the minimum order quantity is 3000 meters.
	0.75	Yellow/Green Blue Brown Red
	1	Yellow/Green Blue Brown Red	A minimum order quantity of one coil is required for cables with 4 cores. For other combinations of cores and colors, the minimum order quantity is 400 meters. If a color is not available, the minimum order quantity is 3000 meters.
	1.5	Yellow/Green Blue Brown Red	A minimum order quantity of one coil is required for cables with 2, 3, or 4 cores. For other combinations of cores and colors, the minimum order quantity is 400 meters. If a color is not available, the minimum order quantity is 3000 meters.
	2.5	Yellow/Green Blue Brown Red	A minimum order quantity of one coil is required for cables with 4 cores. For other combinations of cores and colors, the minimum order quantity is 400 meters. If a color is not available, the minimum order quantity is 3000 meters.
	4	Yellow/Green Blue Brown Red
	6	Yellow/Green Blue Brown Red

YY08 FLEXIBLE POWER CABLE WITH SHIELDING Parameter
아니요.	제품 코드	코어 수 및 단면적	대략적인 외경(mm)	외피 색상
아니요.	제품 코드	(NO.Xm㎡)	대략적인 외경(mm)	외피 색상
1	YY08.02.0050	2×0.5	6.5	검은색
2	YY08.03.0050	3G0.5	6.8	검은색
삼	YY08.04.0050	4G0.5	7.2	검은색
4	YY08.02.0075	2×0.75	7	검은색
5	YY08.03.0075	3G0.75	7.2	검은색
6	YY08.04.0075	4G0.75	7.8	검은색
7	YY08.04.0100	4G1.0	8.5	검은색
8	YY08.02.0150	2×1.5	8.5	검은색
9	YY08.03.0150	3G1.5	9	검은색
10	YY08.04.0150	4G1.5	9.8	검은색
11	YY08.03.0250	3G2.5	10.5	검은색
12	YY08.04.0250	4G2.5	11.5	검은색
13	YY08.04.0400	4G4.0	13	검은색
14	YY08.04.0600	4G6.0	15	검은색

Screened Flexible Power PVC Cables Technical Parameter

Special PVC sheath, with good flexibility.

● 온도 범위: 이동식 설치: -5°C ~ +70°C 고정 설치: -15°C ~ +70°C

● Rated voltage Uo/U: 300/500V

● 테스트 전압: 2000V

● Insulation resistance: Minimum 20 MOhm/km

● Minimum bending radius: Mobile installation: 7.5 times cable diameter Fixed installation: 6 times cable diameter

● Complies with EU RoHS and Reach regulations.

Screened Flexible Power PVC Cables Structure

● Bare copper conductor, fine copper wire Complies with DIN VDE 0295 Class 6 and IEC 60228 Class 6

● 특수 PVC 단열재

● 색상으로 구분된 코어 식별

● Optimum lay-up of cores with optimal pitch

● With yellow-green grounding wire (for cables with 3 cores and above)

● Enhanced tinned copper wire braiding shield

● 최소 전체 차폐 범위 80%

● 특수 PVC 외피

● 블랙 색상(RAL9005), 무광택 마감
