Designed for industrial or outdoor environments where ordinary patch cables fail, this exclusive ultra flexible Category 5E patch cord series from L-com is built to take a beating. These cables utilize an outdoor rated PUR (Polyurethane) jacket that is resistant to UV Damage. The cable is EIA568 color-coded for compatibility with standard installations and has a continuous flex rating into the millions. Contact L-com today with your project requirements.
This Outdoor Industrial PUR Ethernet Cable is designed for data transmission in Ethernet/IP, EtherCAT, and other derivative bus systems, as well as high-flexibility applications. This high-flexibility bus cable features a special structural design and modified outer sheath material, providing high abrasion resistance and dielectric resistance, capable of withstanding long-term acceleration, deceleration, tension, and compression stress, as well as millions of cyclic bends.
Parámetro técnico
●Special PUR sheath with high flexibility.
●Compliant with bus cable specifications.
●Temperature range: Mobile installation: -40°C to +90°C. Fixed installation: -40°C to +90°C.
●Nominal voltage: 30V.
●Test voltage: 500V.
●Minimum insulation resistance: 20 MOhmxkm.
●Minimum bending radius: Mobile installation: 14x cable diameter. Fixed installation: 7x cable diameter.
●Compliance with EU RoHS and Reach regulations.
| Parámetro Ethernet/CAT5e | ||||
| No. | Código de producto | Número de núcleos y área de sección transversal. | Diámetro exterior aproximado (mm) | Color de la funda exterior |
| (NO.Xm㎡) | ||||
| 1 | BUS-HP06.08.0014 | 4x2x0.14 | 6.5 | Black purple green blue |
| Parámetro Ethernet/CAT5e | ||||
| No. | Código de producto | Número de núcleos y área de sección transversal. | Diámetro exterior aproximado (mm) | Color de la funda exterior |
| (NO.Xm㎡) | ||||
| 1 | BUS-HP06.08.0014 | 4x2x0.14 | 6.5 | Black purple green blue |
| Ethernet/CAT7 Parameter | ||||
| No. | Código de producto | Número de núcleos y área de sección transversal. | Diámetro exterior aproximado (mm) | Color de la funda exterior |
| (NO.Xm㎡) | ||||
| 1 | BUS-HP06.08.0012 | 4x2x0.12 | 7 | Black grey |
PUR (disponible) tiene resistencia al aceite, alta resistencia a la abrasión, resistencia a los rayos UV, resistencia a ácidos y álcalis, resistencia a la corrosión química y resistencia a diversos lubricantes.
PUR (disponible) es resistente a bajas temperaturas, especialmente fuerte, resistente a impactos y puede seleccionarse para resistencia a la hidrólisis.
Los modelos especiales con área de sección transversal del conductor, material, blindaje, núcleos de diferentes colores y otras especificaciones de la funda personalizados se pueden personalizar según los requisitos.
