Unshielded YY02 Flexible PVC Control Cable are used for electrical connection in industrial automation, complete sets
of electromechanical equipment, machine tools and other mechanical equipment, logistics transmission systems, production
lines and other control systems. They are especially suitable for fixed installations in industrial environments, dry or humid
indoors, and can also be used for non- Mobile installation with continuous reciprocating motion without forced traction. The
black outer sheath has anti-ultraviolet properties and can be installed outdoors in the open, but direct burial is not allowed.
The cable has good flexibility. The sheath is made of oil-resistant PVC, so that the cable has good oil resistance.
YY02 Flexible PVC Control Cable Technical Parameter
|
Standart
|
UL20276 standardına uygun, ince tel çapı tasarımı
|
|||
|
Kondüktör
|
yüksek kaliteli kalaylı bakır telli bakır tel kullanır
|
|||
|
Yalıtım malzemesi
|
Modifiye PVC
|
|||
|
Çekirdek yapı
|
Küçük adımlı tek iplikçik
|
|||
|
Çekirdek tanıma
|
Below 0.5m㎡ is marked with colored core wires; 0.5m㎡ above, a yellow-green ground wire + black core wire with white numbers
|
|||
|
Dış kılıf
|
Modifiye PVC dostum
|
|||
|
Renk
|
siyah (diğer renkler özelleştirilebilir)
|
|||
|
Bükülme yarıçapı
|
Move in drag chain is more than 7.5 x d,
non-tow chain is moved more than 6 x d,
fixed laying is more than 5 x d
|
|||
|
Movement speed:
|
fixed or low-speed movement, less than 0.3 m/s
|
|||
|
Travel distance
|
Fixedly laid, less than 30 meters, and the signal is attenuated if it is too long.
|
|||
|
Nominal voltaj
|
Uo/U 300/300 V
|
|||
|
Test voltajı
|
1500V
|
|||
|
Başvuru:
|
It is especially suitable for fixed installation of mechanical equipment and machine tools or occasional mobile applications. The flexible cable uses specially modified insulation and sheath materials, has abrasion resistance and medium resistance, and has more than one million periodic bends, and always maintains stability.
|
|||
YY02 Flexible PVC Control Cable Structure
1. Tinned copper (less than 0.5mm2) or bare copper (0.5mm2 and above) conductor thin copper wire, in line with DIN VDE0295 category 6 and IEC 60228 category 6
2. Special PVC insulation
3. Color core wire identification (less than 0.5mm2)
4. Black core wire with continuous white digital code (0.5mm2 and above) The yellow-green ground wire is on the outer layer (3 cores and above)
5. The wire core is stranded in layers with the best pitch
6. Improved tinned copper wire braided shield
7. The minimum comprehensive shielding rate is 80%
8. Special PVC outer sheath
9. Black (RAL 9005) matte
|
HAYIR.
|
Ürün Kodu
|
Çekirdek Sayısı ve kesit alanı
(NO.Xm㎡)
|
Yaklaşık dış çap (mm)
|
Dış kılıf rengi
|
20°C İletken DC direnci
Ah/km
|
|
1
|
YY02.02.0014
|
2×0.14
|
4.0
|
Siyah
|
150
|
|
2
|
YY02.03.0014
|
3×0,14
|
4.2
|
Siyah
|
150
|
|
3
|
YY02.04.0014
|
4×0.14
|
4.5
|
Siyah
|
150
|
|
4
|
YY02.05.0014
|
5×0,14
|
4.8
|
Siyah
|
150
|
|
5
|
YY02.06.0014
|
6×0,14
|
5.2
|
Siyah
|
150
|
|
6
|
YY02.08.0014
|
8×0,14
|
5.5
|
Siyah
|
150
|
|
7
|
YY02.10.0014
|
10×0,14
|
6.4
|
Siyah
|
150
|
|
8
|
YY02.12.0014
|
12×0,14
|
6.5
|
Siyah
|
150
|
|
9
|
YY02.16.0014
|
16×0,14
|
7.2
|
Siyah
|
150
|
|
10
|
YY02.20.0014
|
20×0,14
|
7.8
|
Siyah
|
150
|
|
11
|
YY02.02.0020
|
2×0,2
|
4.4
|
Siyah
|
95
|
|
12
|
YY02.03.0020
|
3×0,2
|
4.6
|
Siyah
|
95
|
|
13
|
YY02.04.0020
|
4×0,2
|
4.9
|
Siyah
|
95
|
|
14
|
5YY02.05.0020
|
5×0,2
|
5.2
|
Siyah
|
95
|
|
15
|
YY02.06.0020
|
6×0,2
|
5.6
|
Siyah
|
95
|
|
16
|
YY02.08.0020
|
8×0,2
|
6.0
|
Siyah
|
95
|
|
17
|
YY02.10.0020
|
10×0,2
|
6.8
|
Siyah
|
95
|
|
18
|
YY02.12.0020
|
12×0,2
|
7.0
|
Siyah
|
95
|
|
19
|
YY02.16.0020
|
16×0,2
|
7.6
|
Siyah
|
95
|
|
20
|
YY02.20.0020
|
20×0,2
|
8.5
|
Siyah
|
95
|
|
21
|
YY02.02.0030
|
2×0,3
|
4.6
|
Siyah
|
71.2
|
|
22
|
YY02.03.0030
|
x0.3
|
4.8
|
Siyah
|
71.2
|
|
23
|
YY02.04.0030
|
4×0,3
|
5.1
|
Siyah
|
71.2
|
|
24
|
YY02.05.0030
|
5×0,3
|
5.5
|
Siyah
|
71.2
|
|
25
|
YY02.06.0030
|
6×0,3
|
6.0
|
Siyah
|
71.2
|
|
26
|
YY02.08.0030
|
8×0,3
|
6.4
|
Siyah
|
71.2
|
|
27
|
YY02.10.0030
|
10×0,3
|
7.2
|
Siyah
|
71.2
|
|
28
|
YY02.12.0030
|
12×0,3
|
7.5
|
Siyah
|
71.2
|
|
29
|
YY02.16.0030
|
16×0,3
|
8.4
|
Siyah
|
71.2
|
|
30
|
YY02.20.0030
|
20×0,3
|
9.0
|
Siyah
|
71.2
|
|
Adedi 1 metre, PUR dış kılıf sipariş etmeniz gerekiyorsa, Adedi 400 metre
|
|||||
