Low -speed YY07 No shielded flexible multi core power cable are mainly used as control and power transmission systems,
which are widely used in sensing technology, computers and equipment control equipment and control engineering; three
cores and three cores have green/yellow protection grounding wires, and core wire twisted cable twisted collisions Short
-distance. The color of the outer cover is: black, you can choose other colors as needed.
Technical Parameter YY07 No shielded flexible multi core power cable
|
標準
|
UL20276規格に準拠した細線径設計
|
|||
|
導体
|
高品質の錫メッキ銅より線を採用
|
|||
|
断熱材
|
変性PVC
|
|||
|
コア構造
|
狭ピッチ単撚り
|
|||
|
コアの認識
|
Color core
|
|||
|
アウターシース
|
変性PVCメイト
|
|||
|
色
|
黒 (他の色もカスタマイズ可能)
|
|||
|
曲げ半径
|
モバイル設置 7.5×ケーブル径 Fixed installation 6x cable diameter
|
|||
|
公称電圧
|
Uo/U 300/500 V
|
|||
|
試験電圧
|
2000 V
|
|||
|
応用：
|
It can be used in multi-joint robots, manipulators, CNC machine tools, non-standard automation equipment, servers/motors, drag
chain systems and other fields. |
|||
Flexible Power Control Cable Structure
1. Bare copper conductor, thin copper wire Complies with DIN VDE 0295 category 6 and IEC 60228 category 6
2. 特殊PVC絶縁
3. Color core wire identification
4. 芯線を最適なピッチで撚り合わせています。
5. With yellow and green grounding wire (3 cores and above)
6. Special PVC outer sheath
7. Black (RAL 9005) matte
|
いいえ。
|
製品コード
|
コア数と断面積
(NO.Xm㎡)
|
おおよその外径（mm）
|
外被シース色
|
20℃ 導体直流抵抗
ああ/km
|
|
1
|
YY07.02.0050
|
2×0.5
|
5.6
|
黒
|
39
|
|
2
|
YY07.03.0050
|
3G0.5
|
6
|
黒
|
39
|
|
3
|
YY07.04.0050
|
4G0.5
|
6.5
|
黒
|
39
|
|
4
|
YY07.02.0075
|
2×0.75
|
6
|
黒
|
26
|
|
5
|
YY07.03.0075
|
3G0.75
|
6.5
|
黒
|
26
|
|
6
|
YY07.04.0075
|
3G0.75
|
7.2
|
黒
|
26
|
|
7
|
YY07.02.0100
|
2X1.0
|
6.4
|
黒
|
19.5
|
|
8
|
YY07.03.0100
|
3G1.0
|
6.9
|
黒
|
19.5
|
|
9
|
YY07.04.0100
|
4G1.0
|
7.8
|
黒
|
19.5
|
|
10
|
YY07.02.0150
|
2×1.5
|
7.5
|
黒
|
13.3
|
|
11
|
YY07.03.0150
|
3G1.5
|
8.2
|
黒
|
13.3
|
|
12
|
YY07.04.0150
|
4G1.5
|
9
|
黒
|
13.3
|
|
13
|
YY07.02.0250
|
2×2.5
|
9
|
黒
|
7.98
|
|
14
|
YY07.03.0250
|
3G2.5
|
9.8
|
黒
|
7.98
|
|
15
|
YY07.04.0250
|
4G2.5
|
11
|
黒
|
7.98
|
|
16
|
YY07.04.00400
|
4G4.0
|
12.8
|
黒
|
4.95
|
|
17
|
YY07.04.0600
|
4G6.0
|
14.4
|
黒
|
3.3
|
|
MOQ 1メートル、PURアウターシースを注文する必要がある場合、MOQ 400メートル
|
|||||
