L-YY07 7 Cores 0.75 mm²(19AMG) Flexible Power Industrial Cable Unscreened
This Flexible Power Industrial Cable Unscreened is highly suitable for fixed installations or occasional movements in mechanical equipment and machine tools. It utilizes specially modified insulation and sheath materials that provide wear resistance and resistance to various media, enabling it to withstand frequent bending and motion while maintaining stability. The high reliability of this flexible cable allows it to endure millions of cycles of bending without damage, while ensuring the quality of electrical signal transmission.
Regardless of the actions and movements required by mechanical equipment and machine tools, this flexible cable can adapt and provide stable power, signal, and data transmission. It is widely used in the industrial sector to ensure the normal operation of mechanical equipment and machine tools, meeting production needs. The outstanding performance of this flexible cable makes it an indispensable component in the mechanical equipment industry.
| MODELLO | Numero di nuclei e area della sezione trasversale (MM²） | COLORE FILO | MOQ |
| YY07 Flexible Power Cable | 0.5 | Yellow/Green Blue Brown Red White Black | 2.3.4.5 cores, minimum order of one roll. For other combinations of cores and colors, minimum order of 400 meters. For colors that are not available, minimum order of 3000 meters. |
| 0.75 | Yellow/Green Blue Brown Red White Black | ||
| 1 | Yellow/Green Blue Brown Red White Black | ||
| 1.5 | Yellow/Green Blue Brown Red White Black | ||
| 2.5 | Yellow/Green Blue Brown Red White Blackr | ||
| 4 | Yellow/Green Blue Brown Red Black | ||
| 6 | Yellow/Green Blue Brown Red Black |
| L-YY07 FLEXIBLE POWER CABLE Parameter | ||||
| NO. | Codice prodotto | Nuclei Numero e area della sezione trasversale | Diametro esterno approssimativo （mm) | Colore guaina esterna |
| (NO.Xm㎡) | ||||
| 1 | L-YY07.02.0050 | 2×0,5 | 5.6 | Nero |
| 2 | L-YY07.04.0050 | 4G0.5 | 6.5 | Nero |
| 3 | L-YY07.04.0075 | 4G0.75 | 7.2 | Nero |
| 4 | YY07.04.0130 | 4G1.3 | 8.3 | Nero |
| 5 | L-YY07.04.0150 | 4G1.5 | 9 | Nero |
| 6 | YY07.04.0200 | 4G2.0 | 10 | Nero |
| 7 | L-YY07.04.0250 | 4G2.5 | 11 | Nero |
| 8 | YY07.04.0330 | 4G3.3 | 11.8 | Nero |
| 9 | MC-YY07.04.0050 | 4G0.5 | 6.3 | Nero |
| 10 | MC-YY07.06.2024 | 4G0.5+2×0.2 | 6.3 | Nero |
| 11 | MC-YY07.04.0075 | 4G0.75 | 6.3 | Nero |
Flexible Power Industrial Cable Unscreened Technical Parameter
- Bare copper conductor, fine copper wire Complies with DIN VDE 0295 class 6 and IEC 60228 class 6
- Isolamento speciale in PVC
- Color-coded cores
- Optimal lay length with layered stranding
- Yellow-green grounding wire (for 3 cores and above)
- Guaina esterna speciale in PVC
- Black color (RAL 9005) with a matte finis
Flexible Power Industrial Cable Unscreened Structure
- Bare copper conductor, fine copper wire Compliant with DIN VDE 0295 class 6 and IEC 60228 class 6
- Isolamento speciale in PVC
- Color-coded core identification
- Optimal lay length with layered stranding
- Yellow-green grounding wire (for 3 cores and above)
- Guaina esterna speciale in PVC
- Black color (RAL 9005) with a matte finish
