It is particularly suitable for the continuous ultra -high flexible high -speed drag chain curved application of machinery and
equipment and machine tools. This ultra -high flexible cable uses special modified insulation materials and external quilt
materials. It has high abrasion resistance and medium resistance, and can withstand long -term acceleration, deceleration,
stretching, and compression stress, as well as periodic curvature of more than 10,000 times or more times. And always maintain high stability.
Technical Parameter Continuous Flex Feedback Encoder Cables
Special PVC sheath, with ultra -high flexibility
temperature range
Mobile installation -5 ° C to +70 “C” C
Fixed installation -15 “C to+80 ° C
· Named voltage UO/U 300/300 V
. Test voltage 1500V
Resistencia de aislamiento:
Minimum 20 mohm x km
Radio de curvatura mínimo:
Instalación móvil Diámetro de cable 6X
Instalación fija Diámetro del cable 4X
O compliance with EU ROHS and Reach regulations requirements
Continuous Flex Feedback Encoder Cables Estructura
Tin -plated copper conductor, fine copper wire
In line with DIN VDE0295 Category 6 and IEC 60228 Category 6 Special PVC insulation
Colored logo
The wire core uses the best section distance to lay layered twisted
Blindaje tejido de alambre de cobre estañado mejorado
Minimum comprehensive shielding rate 80%
. Special PVC outer condom
Black [Ral9005] matte
In line with DIN VDE0295 Category 6 and IEC 60228 Category 6 Special PVC insulation
Colored logo
The wire core uses the best section distance to lay layered twisted
Blindaje tejido de alambre de cobre estañado mejorado
Minimum comprehensive shielding rate 80%
. Special PVC outer condom
Black [Ral9005] matte
Continuous Flex Feedback Encoder Cables Parameter |
||||
| No. | Código de producto | Número de núcleos y área de sección transversal. | Diámetro exterior aproximado (mm) | Color de la funda exterior |
| (NO.Xm㎡) | ||||
| 1 | MC-YY3006.04.0014 | 2x2x0.14 | 5.9 | Negro |
| 2 | MC-YY3006,06.0014 | 3x2x0.14 | 5.9 | Negro |
