Unshielded Multi Cores Tinned Copper Wire Control Cable is used for electrical connection in industrial automation,
complete sets of electromechanical equipment, machine tools and other mechanical equipment, logistics transmission
systems, production lines and other control systems. They are especially suitable for fixed installations in industrial
environments, dry or humid indoors, and can also be used for non- Mobile installation with continuous reciprocating
motion without forced traction. The black outer sheath has anti-ultraviolet properties and can be installed outdoors
in the open, but direct burial is not allowed. The cable has good flexibility. The sheath is made of oil-resistant PVC,
so that the cable has good oil resistance.
المقياس التقني
|
معيار
|
يتوافق مع معيار UL20276، تصميم قطر السلك الرفيع
|
|||
|
موصل
|
تعتمد سلكًا نحاسيًا مجدولًا من النحاس عالي الجودة
|
|||
|
مادة العزل
|
تعديل PVC
|
|||
|
الهيكل الأساسي
|
الملعب الصغير الذي تقطعت به السبل مفردة
|
|||
|
الاعتراف الأساسي
|
Black core with continuous white number code
|
|||
|
الغلاف الخارجي
|
تعديل رفيقة PVC
|
|||
|
لون
|
أسود (يمكن تخصيص ألوان أخرى)
|
|||
|
نصف قطر الانحناء
|
Move in drag chain is more than 7.5 x d, non-tow chain is moved more than 6 x d,
fixed laying is more than 5 x d
|
|||
|
Movement speed:
|
fixed or low-speed movement, less than 0.3 m/s
|
|||
|
Travel distance
|
Fixedly laid, less than 30 meters, and the signal is attenuated if it is too long.
|
|||
|
الجهد الاسمي
|
يو / يو 300/300 فولت
|
|||
|
اختبار الجهد
|
1500 فولت
|
|||
|
طلب:
|
Suitable for various non-standard automated production equipment such as CNC machine tools, industrial robots, servo drives,
woodworking machinery, mask machines, manipulators, dispensing machines, laser equipment, stamping lines, logistics automation, ceramic production equipment, etc., which can withstand long-term acceleration, Deceleration, tensile and compressive stress, and high-speed periodic bending, and always maintain high stability. |
|||
Multi Cores Tinned Copper Wire Control Cable Structure
1.Bare copper conductor, thin copper wire
2.Conforms to DIN VDE0295 category 6 and IEC 60228 category 6 Special PVC insulation
3.Black core wire with continuous white digital code
4.The yellow-green ground wire is stranded in layers with the best pitch on the outer layer (3 cores and above)
5.Special PVC outer sheath
6.Black (RAL 9005) matte
|
لا.
|
كود المنتج
|
عدد النوى ومنطقة المقطع العرضي
(NO.Xm㎡)
|
القطر الخارجي التقريبي (مم)
|
لون الغلاف الخارجي
|
مقاومة موصل تيار مستمر 20 درجة مئوية
أوه / كم
|
|
1
|
YY01.06.0050
|
6×0.5
|
.6.6
|
أسود
|
39
|
|
2
|
YY01.08.0050
|
8×0.5
|
7.0
|
أسود
|
39
|
|
3
|
YY01.10.0050
|
10×0.5
|
8.4
|
أسود
|
39
|
|
4
|
YY01.12.0050
|
12×0.5
|
8.6
|
أسود
|
39
|
|
5
|
YY01.16.0050
|
16×0.5
|
9.4
|
أسود
|
39
|
|
6
|
YY01.06.0075
|
20×0.5
|
10.0
|
أسود
|
39
|
|
7
|
YY01.08.0075
|
6×0.75
|
7.5
|
أسود
|
26
|
|
8
|
YY01.08.0075
|
8×0.75
|
8.2
|
أسود
|
26
|
|
9
|
YY01.10.0075
|
10×0.75
|
9.5
|
أسود
|
26
|
|
موك 1 متر، إذا كنت بحاجة إلى طلب غمد خارجي PUR، موك 400 متر
|
|||||
